Image	Part Number	Application-Lan	Number Of Ports	Speed	Package	Package Length (mm)	Package Width (mm)	Package Height (mm)	Temperature (℃)	PoE Rating	Files
	TC-X-07E	X'FMR	Single	10/100Base-TX	SMD	10.4	11.35	7.2	-40~85℃	NON-PoE	Download
	DIP7201-AG	X'FMR/CMC	Quad	100/1000Base-T	DIP	34.3	18.7	15	-40~85℃	NON-PoE	Download
	DIP9601-AG	X'FMR/CMC	Triple	100/1000Base-T	DIP	28.1	28.9	16.8	-40~85℃	PoE-at	Download
	DIP2401AG	X'FMR/CMC	Single	100/1000Base-T	DIP	15.5	12	12	-40~85℃	NON-PoE	Download
	DIP2005AG	X'FMR/CMC	Dual	10/100Base-TX	DIP	21	12.5	7.2	-40~85℃	NON-PoE	Download
	DIP4801-AG	X'FMR/CMC	Dual	100/1000Base-T	DIP	28	12	12	-40~85℃	NON-PoE	Download
	DIP3601-AG	X'FMR/CMC	Quad	10/100Base-TX	DIP	32.7	8.5	12	-40~85℃	NON-PoE	Download
	DIP2001-AG	X'FMR/CMC	Dual	10/100Base-TX	DIP	25.4	10.16	8.5	-40~85℃	NON-PoE	Download
	DIP1604AG	X'FMR/CMC	Single	10/100Base-TX	DIP	20.9	10.2	7.3	-40~85℃	NON-PoE	Download
	DIP1201G	X'FMR/CMC	Single	10/100Base-TX	DIP	12.8	7.5	6.25	-40~85℃	NON-PoE	Download
